¼ÅÔµÀѳ±ì  >> Expantion Joins  >>
Overall Length [L]

DN
Outside Diameter [mm]
Wall Thickness
The Overall Length, L [mm]
For the Settlement Amount, Y [mm]
Aboveground [mm] Underground [mm] Y=200 Y=500 Y=800
300 323.9 ± 1.6 6.0 6.0 3300 6100 9100
350
355.6 ± 1.6
6.0
6.0
3300
6100
9100
400
406.4 ± 1.6
7.9
6.0
3300
6100
9100
450
457.2 ± 1.6
7.9
6.0
3300
6100
9100
500
508.0 ± 1.6
7.9
6.0
3300
6100
9200
600
609.6 ± 1.6
11.1
6.0
3400
6200
9300
700
711.2 ± 1.6
11.1
6.0
3400
6300
9300
800
812.8 ± 1.6
12.7
7.9
3500
6300
9300
900
914.4 ± 1.6
12.7
7.9
3500
6300
9300
1000
1016.0 ± 1.6
12.7
9.5
3600
6400
9500
1200
1219.2 ± 1.6
15.9
11.1
3600
6500
9500
1350
1371.6 ± 1.6
15.9
11.1
3700
6500
9500
1500
1524.0 ± 1.6
19.1
12.7
3700
6500
9600
1800
1820.0 ± 3.0
25.4
15.9
3900
6700
9700
2000
2020.0 ± 3.0
max.56
19.1
3900
6700
9800
2300
2320.0 ± 3.0
max.56
max.56
4000
6800
9800
